Percentage of false values

This example shows how to detect that the percentage of false values remains above a set threshold.

PROBLEM

The Federal Communication Commission (FCC) political ads public inspection files dataset contains political ad file information that broadcast stations have uploaded to their public inspection files, which are housed on the FCC website.

This information is uploaded to the FCC’s website in PDF form and not machine-readable. However, this dataset includes a content_info table that contains manual annotations of some data fields like advertiser, gross spend, ad air dates and a link to a copy of the PDF, which can be found on Google Cloud Storage.

The invalidOcr column indicates if the OCR does match the raw file text (false value) or does not (true value). In case of the true value, the OCR process needs more work and the file is not ready to be transcribed.

We want to verify the percentage of false values in the invalidOcr column, which will tell us what percentage of data is ready to be transcribed.

SOLUTION

We will verify the data of bigquery-public-data.fcc_political_ads.content_info using profiling bool_false_percent column check. Our goal is to verify that the percentage of false values on invalidOcr column does not fall below 99%.

In this example, we will set three minimum percentage thresholds levels for the check:

  • warning: 99.0%
  • error: 98.0%
  • fatal: 95.0%

If you want to learn more about checks and threshold levels, please refer to the DQO concept section.

VALUE

If the percentage of data that is available for transcription drops below 99%, a warning alert will be triggered.

Data structure

The following is a fragment of the bigquery-public-data.fcc_political_ads.content_info dataset. Some columns were omitted for clarity.
The invalidOcr column of interest contains both TRUE and FALSE values.

contentInfoId advertiser grossSpend infoSource invalidOcr
5116276091387904 J Hawley for Missouri Senate-R 2847500 MANUAL TRUE
5101779805011968 Friends of Michael Guest 307500 MANUAL FALSE
5948640182927360 ALISON HARTSON 2018 360000 MANUAL FALSE
5724690924437504 Friedman for Congress 2247500 MANUAL TRUE
5660449924186112 WALDEN, GREG 85000 MANUAL FALSE
4831078887981056 ASHFORD FOR CONGRESS 1557500 MANUAL FALSE
6030938634977280 Dr. Jim Maxwell 2735000 MANUAL TRUE
5199588961026048 CROWLEY FOR CONGRESS 1170000 MANUAL FALSE
4925540251205632 Alaskans For Don Young 1500800 MANUAL FALSE
5155591651590144 POL/ Ted Cruz/R/US SEN / TX 1610000 MANUAL FALSE

YAML configuration file

The YAML configuration file stores both the table details and checks configurations.

In this example, we have set three minimum percentage thresholds levels for the check:

  • warning: 99.0%
  • error: 98.0%
  • fatal: 95.0%

The highlighted fragments in the YAML file below represent the segment where the profiling bool_false_percent check is configured.

# yaml-language-server: $schema=https://cloud.dqo.ai/dqo-yaml-schema/TableYaml-schema.json
apiVersion: dqo/v1
kind: table
spec:
  incremental_time_window:
    daily_partitioning_recent_days: 7
    monthly_partitioning_recent_months: 1
  columns:
    contentInfoId:
      type_snapshot:
        column_type: STRING
        nullable: false
    advertiser:
      type_snapshot:
        column_type: STRING
        nullable: true
    candidate:
      type_snapshot:
        column_type: STRING
        nullable: true
    grossSpend:
      type_snapshot:
        column_type: INT64
        nullable: true
    infoSource:
      type_snapshot:
        column_type: STRING
        nullable: true
    invalidOcr:
      type_snapshot:
        column_type: BOOL
        nullable: true
      profiling_checks:
        bool:
          profile_false_percent:
            warning:
              min_percent: 99.0
            error:
              min_percent: 98.0
            fatal:
              min_percent: 95.0
    ocrFileDirectory:
      type_snapshot:
        column_type: STRING
        nullable: true
    organization:
      type_snapshot:
        column_type: STRING
        nullable: true
    periodEnd:
      type_snapshot:
        column_type: STRING
        nullable: true
    periodStart:
      type_snapshot:
        column_type: STRING
        nullable: true
    product:
      type_snapshot:
        column_type: STRING
        nullable: true
    rawFileLink:
      type_snapshot:
        column_type: STRING
        nullable: true
    rawFilePath:
      type_snapshot:
        column_type: STRING
        nullable: true
    sourceId:
      type_snapshot:
        column_type: STRING
        nullable: true
    agency:
      type_snapshot:
        column_type: STRING
        nullable: true

Running the checks in the example and evaluating the results using the graphical interface

The detailed explanation of how to run the example is described here.

To execute the check prepared in the example using the graphical interface:

Navigating to a list of checks

  1. Go to Profiling section.

  2. Select the table or column mentioned in the example description from the tree view on the left.

  3. Select Advanced Profiling tab.

  4. Run the enabled check using the Run check button. Run check

  5. Review the results by opening the Check details button. Check details

  6. You should see the results as the one below. The actual value in this example is 99, which is above the minimum threshold level set in the warning (99.0%). The check gives a valid result (notice the green square on the left of the name of the check).

Bool-false-percent check results

  1. After executing the checks, synchronize the results with your DQO cloud account sing the Synchronize button located in the upper right corner of the graphical interface.

  2. To review the results on the data quality dashboards go to the Data Quality Dashboards section and select the dashboard from the tree view on the left. Below you can see the results displayed on the Daily tests per column dashboard showing results by connections, schemas, data group and tables.

Bool-false-percent check results on daily tests per column dashboard

Running the checks in the example and evaluating the results using DQO Shell

The detailed explanation of how to run the example is described here.

To execute the check prepared in the example, run the following command in DQO Shell:

check run

You should see the results as the one below. The check shows a valid results what means that the percentage of false values in the invalidOcr column exceeds 99%.

Check evaluation summary per table:
+-----------------+------------------------------+------+--------------+-------------+--------+------+------------+----------------+
|Connection       |Table                         |Checks|Sensor results|Valid results|Warnings|Errors|Fatal errors|Execution errors|
+-----------------+------------------------------+------+--------------+-------------+--------+------+------------+----------------+
|fcc_political_ads|fcc_political_ads.content_info|1     |1             |1            |0       |0     |0           |0               |
+-----------------+------------------------------+------+--------------+-------------+--------+------+------------+----------------+

For a more detailed insight of how the check is run, you can initiate the check in debug mode by executing the following command:

check run --mode=debug

In the debug mode you can view the SQL query (sensor) executed in the check.

**************************************************
Executing SQL on connection fcc_political_ads (bigquery)
SQL to be executed on the connection:
SELECT
    CASE
        WHEN COUNT(*) = 0 THEN 100.0
        ELSE 100.0 * SUM(
            CASE
                WHEN NOT analyzed_table.`invalidOcr`
                    THEN 1
                ELSE 0
            END
        ) / COUNT(*)
    END AS actual_value,
    CURRENT_TIMESTAMP() AS time_period,
    TIMESTAMP(CURRENT_TIMESTAMP()) AS time_period_utc
FROM `bigquery-public-data`.`fcc_political_ads`.`content_info` AS analyzed_table
GROUP BY time_period, time_period_utc
ORDER BY time_period, time_period_utc
**************************************************

You can also view the results returned by the sensor. The actual value in this example is 99.95%, which exceeds the minimal threshold level set in the warning (99%).

Finished executing a sensor for a check false_percent on the table fcc_political_ads.content_info using a sensor
definition column/bool/false_percent, sensor result count: 1

Results returned by the sensor:
+----------------+------------------------+------------------------+
|actual_value    |time_period             |time_period_utc         |
+----------------+------------------------+------------------------+
|99.9540159411404|2023-04-26T09:06:53.386Z|2023-04-26T09:06:53.386Z|
+----------------+------------------------+------------------------+
**************************************************
